Belt Alignment

Belt Alignment Set

Package contents: X3 Magnetic target, Х1 Screw driver, Х1 Laser source

What's included?

X3
Magnetic target
Х1
Screw driver
Х1
Laser source

The tool is attached in a few seconds and you can easily see the laser line projected onto the targets. When the line lies in the slots of the targets, the machine is in the right position. The result is a fast, precise alignment. Much faster and more accurate than measuring with earlier, conventional methods. Alignment can be made by one operator. Also suitable for non-magnetic sheaves.

Buy this product

We intent to establish long-term partnerships founded on our shared success.

Please do not hesitate to contact one of our partners for more details about VIBRO-LASER measurement and alignment tools.

Find a distributors

Other products

Magnetic Base Brackets

Magnetic Base Brackets are specialized mounting solutions designed for securely attaching measuring units on large diameter shafts with powerful magnets to ensure a firm hold, providing a reliable and stable connection for laser alignment.

Standart V-Brackets

V-bracket with chain is used to fix the measuring units on the shaft diameter 25 – 225 mm / 1 in – 8.6 in.

Extension Rods 120 mm

The VIBRO-LASER 120 mm rod spare part includes a set of 120 mm (4.7 in) threaded rods designed for use with shaft alignment tools.

Slim V-Brackets

Slim VIBRO-LASER offset brackets are specifically designed stylish accessories for situations where there is limited space between the coupling and the machine, making it impossible to install a standard v-bracket for laser alignment.

Extension Rods 300 mm

The VIBRO-LASER 120 mm rod spare part includes a set of 300 mm (11.8 in) threaded rods designed for use with shaft alignment tools.

Extension Chains

They are used for large shafts to extend the standard chain, when its length is insufficient.

Magnetic V-brackets

VIBRO-LASER Magnetic V-brackets are specialized mounting solutions designed for securely attaching measuring units to the side of a coupling. These brackets utilize powerful magnets to ensure a firm hold, providing a reliable and stable connection for laser alignment, allowing for easy installation and removal of the measuring units as needed.

Offset Brackets

VIBRO-LASER offset brackets are engineered for environments where space constraints and the presence of projecting machine parts pose challenges to the installation and operation of laser alignment units.

Non-rotating Brackets

VIBRO-LASER non-rotating shaft brackets are specifically designed to provide a stable and secure attachment point for measurement devices, ensuring accurate readings during shaft alignment without the risk of interference from rotational motion.

Extension Rods 160 mm

The VIBRO-LASER 120 mm rod spare part includes a set of 160 mm (6.3 in) threaded rods designed for use with shaft alignment tools.

Extension Rods 250 mm

The VIBRO-LASER 120 mm rod spare part includes a set of 250 mm (9.8 in) threaded rods designed for use with shaft alignment tools.

Cardan Shaft Bracket Fixture

Cardan shaft set is used to mount bracket fixtures between the machines with offset axes of rotation. Discover how to effectively align machine shafts using a cardan shaft bracket to overcome offset issues.

VLRTC Display Unit

The Display Unit by VIBRO-LASER is the ultimate rugged tablet combining versatility and durability. Its ergonomic design ensures ease of use and is optimized for field maintenance. Li-ion Battery 8-hour battery life based on test configurations. Storage: eMMC 64GB.
